We provide premium turnkey production lines for manufacturing mobile phone tempered glass screen protectors, capable of producing both clear standard glass and silk-screen printing-type glass. Our complete machinery assembly includes: Glass Cutting Machine, High Precision CNC Machine, Polishing Machine, Cleaning Machine, Tempering Furnace, Film Cutting Machine, Laminating Machine, AF Spraying Machine, Silk-Screen Printing Machine and so on. Today we are introducing the production process of the complete tempered glass film production line.
1.Cutting Glass
Mobile tempered glass of screen protector glass cutting machine suitable for 0.2-4.0mm optical glass, float glass, special glass and other glass precision slice cutting, such models are widely used in mobile tempered glass of screen protector industry, optical lens processing industry, decoration, precision electronics industry.
Mobile tempered glass of screen protector glass cutting machine can be compatible with Mill/CAD/NC files, servo system the special data optimization, high precision, fast speed. Granite countertops, base, stable physical properties, no deformation.
Click to learn more：
https://www.ndmachinery.com/shows/145/63.html
2. Grinding Glass
Mobile tempered glass CNC machine ND1200-4 can process four work position at same time, it is suitable for precision processing of glass. Mobile tempered glass CNC machine is based on granite body, gantry and guide rail bases. It is equipped with a high-precision screw guide rail and high-power/RPM spindle.
Mobile tempered glass CNC machine ND1200-4 has extensive performance characteristics. It is application for car central control touch screen glass, smart appliance glass, smart home glass, smart terminal protection glass, smart security glass, smart wearable glass industry.
Click to learn more：
https://www.ndmachinery.com/shows/146/64.html
3. Polishing Glass
Mobile tempered glass of screen protector polishing machine is mainly for 2.5D surface polishing design, and for the size, different materials, mobile phone lenses, flat lenses, watches, touch screen polishing, grinding treatment.
Mobile tempered glass of screen protector polishing machine use vacuum adsorption, one-button operation easy to learn. On the processing plate can be lifted for a variety of products.
Click to learn more：
https://www.ndmachinery.com/shows/147/65.html
4. Rough Cleaning Glass
Mobile tempered glass cleaning machine 3 groove clean the polishing powder on glass use the water after Polishing Machine.
Mobile tempered glass cleaning machine automatic cleaning objects automatic loading to stainless steel baskets. PLC & Touch screen automatic control system, easy operate and convenient instruction. All tanks by stainless steel made to anti acid base.
Click to learn more：
https://www.ndmachinery.com/shows/148/66.html
5. Tempering Glass
Mobile tempered glass of screen protector tempering machine furnace for temper glass to make the glass strength and up to 9H. Warming and strengthening the glass.
Mobile tempered glass of screen protector tempering machine furnace has the characteristics of safety, energy saving, convenient operation, low investment, etc. It is suitable for chemical toughening processing of small batch glass and for experimental furnace.
Click to learn more：
https://www.ndmachinery.com/shows/149/67.html
6. Fine Cleaning Glass
Mobile tempered glass of screen protector fine cleaning machine 10 groove clean the glass again and getting ready for laminating. Clean the glass surface.
Mobile tempered glass of screen protector fine cleaning machine automatic cleaning objects automatic loading to stainless steel baskets. PLC & Touch screen automatic control system, easy operate and convenient instruction. All tanks by stainless steel made to anti acid base.
Click to learn more：
https://www.ndmachinery.com/shows/148/68.html
7. Printing Ink
Mobile tempered glass ink printing machine printing color on the glass.
Mobile tempered glass ink printing machine printing, lifting all the high precision linear guide, variable frequency drive, printing stable, accurate positioning. Special design momentary synchronization off-grid device, to avoid the shadow of the printed matter or paste board.
Click to learn more：
https://www.ndmachinery.com/shows/152/75.html
8. Drying Ink
Mobile tempered glass screen glass printing ink oven box made of angle steel, sheet steel. Housing and studio filled with glass fiber insulation and insulation. Heating system unit at the top of the studio. Horizontal circulation ventilation, so that the temperature inside the box more uniform, this type of drying box can effectively avoid the existing indoor temperature gradient and temperature overshoot, and can improve the temperature uniformity within the studio.
Click to learn more：
https://www.ndmachinery.com/shows/155/76.html
9. Cutting Film
Mobile tempered glass of screen protector AB film glue cutting machine for AB Film glue, OCE, double-sided, textured paper, dustproof net, rubber pad, PE foam, shoe material, leather products, self-adhesive, sponge, protective film.
Mobile tempered glass of screen protector AB film glue cutting machine for mobile phone protection film design, easier to operate. With high speed per hour can be amazing out of 16000 mobile phone protection film, is the general die-cutting machine 1-2 times, is punch press die cutting machine 4 - 5 times output.
Click to learn more：
https://www.ndmachinery.com/shows/150/69.html
10. Lamaniting Film
Mobile tempered glass of screen protector AB film glue laminating pasting machine for OCA/AB adhesive film of various flat glass and protective film for plywood.
AB film glue laminating machine has no bubbles and indentation of laminating process. Roller pressure and wheel parallelism manually adjustable (can be customized cylinder pressure adjustment). On the suction cup flip smooth. Comes with foot function, and can be any combination of function keys to fit.
Click to learn more：
https://www.ndmachinery.com/shows/151/70.html
https://www.ndmachinery.com/shows/151/71.html
11. Spraying Anti-fingerprint Oil
Mobile tempered glass anti-fingerprint coating oil spraying machine used in glass protective film, silk screen glass film, explosion-proof film, acrylic, metal and other flat labeling.
Mobile tempered glass anti-fingerprint coating oil spraying machine use rotating material to improve feeding efficiency. Automatic tear film, labeling, single (double) spray gun oiling machine to solve three processes, saving people. The electric eye controls the position of the label, and the replacement product automatically adjusts the label position.
Click to learn more：
https://www.ndmachinery.com/shows/153/72.html
https://www.ndmachinery.com/shows/153/73.html
https://www.ndmachinery.com/shows/153/74.html
Are you interested in our products, please feel free to contact us.
We have professional engineers available to answer your technical questions.
